From Design to Build to Debug

a Faster, Safer Solution

  • Design was driven with a basic concept:

    CONVENIENCE = SAVINGS & IMPROVED SAFETY

    About

    Created by controls engineers and industrial electricians for the purpose of improving design, build and machine uptime while embracing the latest work place electrical safety standards.

    Features

    Benefits

    • One part number to Design, Procure and Install
    • Designed for installation on new or existing control panels
    • Removes exposure to line side 3 phase supply power
    • Facilitates safer testing and troubleshooting of lower voltage control circuits
    • Improves machine uptime by reducing PLC, HMI and network boot up time

    Savings

    Improves design, procurement and build time

    Safety

    Reduces exposure and facilitate safe work practices

    Convenience

    Increase machine or automation investment up time

    Options

    Specifiy control voltage 24VDC

    Add: programming receptacle, auxiliary contacts, print pocket

    #1

    Significant Savings

    Significant Savings

    BSAFE is cost effective because of its modular time saving nature. Time in engineering, procurement and custom build are all costly elements of traditional systems. With the plug and play of BSAFE, your benefit is an overall savings.

    #2

    Improved Safety

    Improved Safety

    BSAFE is a safer solution because it reduces shock hazard by isolating the line side circuits of the main 3 phase disconnect. The BSAFE moves the prospective arc source away from the qualified worker and out of the interior of control panel after LOTO; this in conjunction with recommended current limiting devices on the feeder circuit and other incident energy reduction methods, reduce arc flash hazards. The BSAFE also trains & instructs the worker in achieving an electrically safe work condition. Lastly it alerts the qualified worker to the presence of live voltage.

    #3

    Increased Convenience

    Increased Convenience

    The BSAFE adds convenience by providing a separate power source for control voltages. PLCs, HMls, network switches and other controls electronics can remain powered during LOTO. Testing, troubleshooting and voltage measurement on circuits 50V or less can be accomplished by the qualified worker while the panel is in an electrically safe work condition.

    FAQ SECTION

    How does the BSAFE panel improve work place safety?

    1. Reduces Shock Hazards –In traditional control panels the main 3 phase disconnect is mounted inside the control panel where the line side circuit parts of the main disconnect switch remain live when locked out. This exposes the qualified worker to energized circuit conductors when the door is open despite the disconnect being LOTO. Consequently, limited approach and restricted approach boundaries (per NFPA 70E) now apply when the panel door is opened. The BSAFE isolates these line side circuits that remain live when the main 3 phase disconnect is off. The BSAFE panel prevents unintentional access to these live conductors and any possibility of crossing the limits of approach due to the physical barrier of the control panel wall and separate BSAFE panel.
    2. Reduces Arc Flash Hazards – The BSAFE moves the prospective arc source away from the qualified worker and out of the interior of control panel after LOTO; this in conjunction with recommended current limiting devices on the feeder circuit and other incident energy reduction methods, reduce arc flash hazards.
    3. Trains and instructs – The BSAFE guides the qualified worker through the steps of achieving an electrically safe work condition.
    4. Alerts – The BSAFE alerts the qualified worker to the status of live 3 phase power by means of voltage presence indicator lights.
    5. Facilitates safer testing & troubleshooting – The BSAFE provides a means of testing, troubleshooting and voltage measurement of live circuits 50V or less after the panel has been placed in an electrically safe work condition. Technicians, programmers and electricians can accomplish most of their troubleshooting work in an electrically safe work condition unlike traditional systems.

    How does the BSAFE save me money?

    One part number to design, procure and install.

    1. Faster Schematic Design:
      • Download the free standard DWGs.
      • Insert the electrical schematic into your drawing set
      • Insert the panel drawing onto your exterior panel layout
      • Provide the cutout template to your panel fabricator for precut holes
    2. Faster Panel Manufacturing:
      • One part number to procure and install.
      • Use the provided hole cutout template or download the template and provide it to your panel fabricator for pre-cut holes and an even faster installation.
      • Each BSAFE comes with all the wire, fittings & fastening hardware and set-up instructions required.
